Radar Rain Sensor

Release time：2022-02-24
Update time：2022-03-01
4402 0
Inquiry Request for Sample
Product Description Specifications Downloads Video FAQ Purchase
Products Description

BGT-WS2E adopts advanced small 24GHz Doppler radar, the speed rate of drops is registered with a 24 GHz radar system. By comparison between the speed rate and the size of drops, the quantity of rain or its intensity will be registered. The rain/precipitation type (rain/snow/snow-covered rain/freezing rain/hail) is determined thanks to the speed rate of the rain. Resolution up to 0.1mm, without maintenance.

Data Sheet
Model
BGT-WS2E
Type of precipitation
No precipitation, Rain
Measurement surface
8cm2
Measurement Range
0.01-200mm/hour (liquid precipitation)
Accuracy
±10% of the measured value for liquid
Measuring drop size range
0.5-5.0mm
Resolution
0.1mm
Sample rate
1 time per second
Communication interface
RS485、RS232
Protocol
ModBus、NMEA-0183、ASCII
Voltage
DC7-30V; 130mA@12V
Operating Temperature
-40℃ － +70℃
Operating Humidity
0-100%
Size
Ø105 * 178mm
Material
Aluminum alloy +ABS
Net Weight
0.45kg
Application
weather Station.
Hydrology



Smart City
